Tilt Pad Thrust Bearings

Meeting Industry Challenges

Waukesha Bearings tilt pad thrust bearings, available with or without equalizing links, are designed to transfer high axial loads from rotating shafts with minimum power loss, while simplifying installation and maintenance.

Patented design features allow for optimized performance in a variety of applications and address industry-wide challenges such as axial vibration.

Small polymer-lined tilt pad thrust bearings with large equalized tilt pad thrust bearing

Bearing Design

Each bearing consists of a series of pads supported in a carrier ring (retainer). Each pad is free to tilt, resulting in a self-forming hydrodynamic film. The self-equalizing design balances the load between the pads and accommodates misalignment or deflection between the bearing and collar.

The carrier ring may be in one piece or in halves, and the size and number of pads are selected to suit the operating conditions. In addition, pads can be supplied with center pivots for bi-directional running or offset pivots for increased load capacity and lower pad temperatures.

Temperature sensors are typically installed in two pads per thrust bearing.

Lubrication Systems

Flooded Lubrication

The conventional method of lubricating tilt pad thrust bearings is to flood the housing with oil, using an orifice on the outlet to regulate the flow and maintain pressure. To minimize leakage, seal rings are required where the shaft passes through the housing.

‘Directed Lubrication’

Where mean sliding speeds in excess of 50 m/s are expected, the high power losses caused by turbulence in the oil in flooded lubrication systems can be largely eliminated by employing the Waukesha Bearings system of ‘Directed Lubrication’.

As well as reducing power loss by (typically) 50%, ‘Directed Lubrication’ reduces bearing surface temperatures and in most cases oil flow. No seal rings are required on the shaft.

Self-equalizing thrust bearings are typically supplied with ‘Directed Lubrication’ even at relatively low sliding speeds to avoid the need for oil seals.

Directed Lubrication' on a tilt pad thrust bearing

Materials

Standard pads are steel backed with a babbitt lining. High operating speeds and loads, as well as high oil inlet temperatures, increasingly take bearing design beyond the limits of babbitt, however, as do applications using lubrication by process fluids.

Waukesha Bearings offers the widest choice of materials to accommodate operating conditions, and leads in the industry in the design, development and application of advanced materials.

Alternative material options for tilt pad thrust bearings include:

Copper chrome backed pads faced with babbitt
Steel-backed pads faced with aluminum tin
Steel-backed pads faced with polymer
Solid polymer pads
Steel-backed pads faced with ceramic or cermet

Explore Advanced Materials

Advantages

Proven designs for non-equalizing and self-equalizing tilt pads
Compact designs to save space
Pad number, pivot offset and pad material designed to suit specific application
Pad optimization provides low frictional drag and improved oil circulation
Industry-standard ‘Directed Lubrication’

Specialty Designs

Flexure Pivot tilt pad thrust bearing with copper pads

Flexure Pivot® Tilt Pad Thrust Bearings

The Flexure Pivot post support is custom designed to provide an optimum wedge ratio at design load conditions, resulting in an increase in the load capacity and a significant reduction in horsepower loss.

Hidrax® HT Thrust Bearings

For the high temperatures in steam-assisted gravity drainage (SAGD) wells, Waukesha Bearings supplies tilt pad thrust bearings with durable ceramic/cermet faces.

Tilt Pad Journal Bearings

Waukesha Bearings also provides custom-engineered tilt pad journal bearings, designed to transfer radial loads from rotating shafts with minimum power loss and optimum dynamic characteristics.
